A06229 – A06230 Jack Trolley

Category:

The lightest, most agile and most compact jack stands trolley on the market. Optional trolley, allow a single operator to quickly move the jack stand as needed. Provided with pneumatic wheels, suitable for uneven ground. The handle is adjustable in three positions in order to pick and move the jack stand at different height regulations.

Datasheet Download

A06229 – A06230

Description

A06229

A: 691 mm / 27.2
B: 1,158 mm / 45.5”
C: 1,662 mm / 65.4”
D: 283 mm / 11.1”
E: 842 mm / 33.1”
F: 1,496 mm / 58.8”
G: 418 mm / 16.4”
Weight: 22 kg / 48 lb

A06230

A: 635 mm / 25”
B: 1,204 mm / 47.4”
C: 1,631 mm / 64.2”
D: 142 mm / 5.5”
E: 697 mm / 27.4”
F: 1,405 mm / 55.3”
G: 418 mm / 16.4”
Weight: 21 kg / 46 lb
